FYOU PMEC, provides API EUE and NUE 8 and 10 round tubing working and reference master gages per API Specification 5B for sizes from 1.050 to 4-1/2 inches in diameter. All working gages are manufactured and certified using a certified API reference master gage as required by the standard.
| UPSET (E.U.E) TUBING WORKING/MASTER/TAPER GAGES | |||||
| SIZE | Outer Dia. | T.P.I | T.P.F | TAPER | ANGLE |
| 1.050 EUE/UP TBG | 26.67 | 10 | 3/4 | 1:16 | 60° |
| 1.315 EUE/UP TBG | 33.4 | 10 | 3/4 | ||
| 1.660 EUE/UP TBG | 42.16 | 10 | 3/4 | ||
| 1.900 EUE/UP TBG | 48.26 | 10 | 3/4 | ||
| 2 3/8 EUE/UP TBG | 60.33 | 8 | 3/4 | ||
| 2 7/8 EUE/UP TBG | 73.03 | 8 | 3/4 | ||
| 3 1/2 EUE/UP TBG | 88.9 | 8 | 3/4 | ||
| 4 EUE/UP TBG | 101.6 | 8 | 3/4 | ||
| 4 1/2 EUE/UP TBG | 114.3 | 8 | 3/4 | ||
Instructions:
1）Implementation of standards：API SPEC 5B：2017
2）Material: GCr15， Measuring surface hardness 60-63HRC;
3）Comes with the Long Form calibration certificates
How to order?
For example:
Pls mark : Master Gauges:3 1/2 UP TBG RING&PLUG, or 3 1/2 UP TBG BOX&PIN,
and E-mail to: sales@fyougauges.com
